AdastraRM360S Mixer-Amplifier 100V

A rack-mountable 5-channel mixer amplifier, tailored to commercial sound installations, that can either be used as a 100V line amplifier or a standard low-impedance amp. Versatile input options include XLR (with switchable phantom power), mic/line jack, and RCA line. Features an inbuilt FM radio tuner, front-mounted SD and USB ports, and Bluetooth connectivity, all controlled via an integrated media player for hassle-free playback. A switchable ÔvoiceoverÕ feature automatically lowers the background music volume when a signal is detected via mic input 1 and rear panel 24V contacts can mute all except mic input 1 when triggered.

SPECIFICATIONS

• - Weight: 14.98 kgs

• - SKU: 953216

• - Mains power: 110/240Vac, 50/60Hz (IEC)

• - DC power: 24Vdc (screw terminals)

• - Inputs: Mic XLR, 2 x mic/line jack, 2 x RCA line

• - Input sensitivity : mic 1 (balanced): -53dBV

• - Input impedance : mic 1: 5k Ohms

• - Input sensitivity : line (unbalanced): -15dBV (-18.5dBV line 5)

• - Input impedance : inputs 2-5: 1k Ohms

• - Line output: RCA

• - Controls: Mic1, mic/line2+3, line4+5, bass, treble, master volume

• - Equalizer : bass: 100Hz ±10dB

• - Equalizer : treble: 10kHz ±10dB

• - Rear panel switches: Phantom, Vox, Mic/Line (2 + 3)

• - Phantom power: +20V (mic 1 input)

• - Audio source: USB/SD player, FM tuner and Bluetooth receiver
• - Emergency control: 24V contacts - mute all except Mic.1 when triggered

• - Bluetooth version: 2.0

• - THD: <1.0%
