BossOC-5 Exp Guitar Effects
Show all:
Electric & Bass Guitars,Octave
DescriptionRead moreRead less
The performance of octave pedals is redefined by the BOSS OC-5. The iconic mono OC-2 from 1982 is faithfully recreated in vintage mode, and with the addition of an octave-up feature, a range of three octaves is now open for imaginative experimentation. The OC-5 has the broadest range, highest sound quality, and best playability of any octave stomp to date, including fat, low mono sounds, octave-shifted chords, and more.
Features
- The industry-standard octave pedal, updated with enhanced features
- Newly developed tracking technology provides more accurate response and natural feel with no latency
- Vintage mode faithfully reproduces the mono sound of the original OC-2
- Poly mode for chord playing; Range knob sets the note range where the effect is applied
- Lowest Range setting in Poly mode applies the octave effect to only the lowest note in a chord
- New octave-up effect, available on its own or blended with octave-down effects
- Mode switch optimizes the tracking engine for guitar or bass
- Direct out for wet/dry setups
- BOSS five-year warranty
SPECIFICATIONS
- - Nominal Input Level: -20 dBu
- - Input Impedance: 1 M ohm
- - Nominal Output Level: -20 dBu
- - Output Impedance: 1 k ohm
- - Recommended Load Impedance: 10 k ohms or greater
- - Bypass: Buffered bypass
- - Controls: Pedal switch, GUITAR/BASS switch, VINTAGE/POLY switch, DIRECT LEVEL knob, +1OCT knob, -1OCT knob, -2OCT/RANGE knob
- - Indicator: CHECK indicator (Serves also as battery check indicator)
- - Connectors: INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
DIRECT OUT jack: 1/4-inch phone type
DC IN jack - - Power Supply: Alkaline battery (9 V, 6LR61 or 6LF22)
AC adaptor (PSA series: sold separately) - - Current Draw: 60 mA
- - Expected battery life under continuous use: Alkaline: Approx. 5 hours
*These figures will vary depending on the actual conditions of use. - - Accessories: Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Alkaline battery (9 V, 6LR61) - - Options (sold separately): AC adaptor: PSA series
SIZE AND WEIGHT
- - Width: 73mm l 2-7/8 inches
- - Depth: 129mm l 5-1/8 inches
- - Height: 59mm l 2-3/8 inches
- - Weight (including battery): 440g l 4 lb
