PresonusEris E8 XT Studio Monitor UK
Show all:
Studio Monitoring,Pro Audio
Description
Read moreRead less
The Eris E8 XT enhances the best-selling studio monitors with deeper lows and a wider, more controlled sweet spot, thanks to its new EBM waveguide.
FEATURES
Components and construction
- 8-inch woven composite low-frequency transducer
- 1.25-inch (31.75 mm), ultra-low-mass, silk-dome, high-frequency transducer
- 100˚(H) x 60˚(V) EBM waveguide for wide sweet spot
- Front-firing acoustic port for superior bass-frequency reproduction
- Optimized, resonance-suppressing internal bracing
- 105 dB maximum continuous SPL
User controls
- HF Adjust (±6 dB, continuously variable)
- Midrange Adjust (±6 dB, continuously variable)
- Acoustic Space settings (flat, -2, -4 dB) for accurate mixing contour
- Highpass filter (Off, 80 Hz, 100 Hz)
Power and safety
- 140 watt, Class AB biamplification
- RF interference, output current limiting, over-temperature, transient, and subsonic protection
- Amplifier “soft start” feature eliminates popping on power-up
- Internal power supply with IEC connector
- Power switch with on/off LED
Inputs and outputs
- Balanced XLR/¼-inch
- Unbalanced RCA inputs (E5/E8)
Software
- Studio One® Prime and Studio Magic Software Suite ($1,000 value!)
SPECIFICATIONS
INPUTS | PROTECTION | |||
1- Balanced XLR | RF interference | |||
1- Balanced ¼” TRS | Output-current limiting | |||
1- Unbalanced RCA | Over-temperature | |||
Turn-on/off transient | ||||
PERFORMANCE | Subsonic filter | |||
Frequency Response | 35 Hz - 20 kHz | External mains fuse | ||
Crossover Frequency | 2.2 kHz | |||
LF Amplifier Power | 75W | POWER | 100-120V ~50/60 Hz or 220-240V ~50/60 Hz Cabinet | |
HF Amplifier Power | 65W | |||
Peak SPL (@ 1 meter) | 105 dB | CABINET | Vinyl-laminated, medium-density fiberboard | |
LF Driver | 8” reinforced woofer | |||
HF Driver | 1.25” silk dome tweeter | PHYSICAL | ||
Input Impedance | 10 kΩ | Width | 9.75” (247.65 mm) | |
Dispersion | 100 degrees horizontal by 60 degrees vertical | Depth | 11.5” (292.1 mm) | |
Height | 16” (406.4 mm) | |||
USER CONTROLS | Weight | 23 lbs (10.43 kg) | ||
Volume Range | A-type taper | |||
MF Control | -6, 0, +6 dB | |||
HF Control | -6, 0, +6 dB | |||
Low Cut | Flat, 80 Hz, 100 Hz | |||
Acoustic Space | Flat, -2 dB, -4 dB |
