PresonusHP4 4-Band Headphone Amp
Show all:
Amplifier Headphones,Pro Audio
Description
Read moreRead less
The PreSonus® HP4 headphone-distribution system delivers powerful, clear sound for sessions and live performances. It features left/right line inputs, four headphone outputs, stereo-to-mono summing, and level control for each headphone. Compact and easy to set up, the HP4 can sit on a table or be rack-mounted, taking up just a third of a rackspace. Expand by connecting additional units if needed. Upgrade to the HP4 and experience high-quality sound for your music.
FEATURES
- 4 screaming-loud (130 mW per channel) stereo ¼” headphone outputs (front panel)
- 2 balanced ¼” line outputs (monitor outputs)
- 2 balanced ¼” line inputs
- Headphone level control for each channel
- Mono summing switch for each channel
- Monitor level control
- Monitor mute switch
- Daisy-chain multiple units via monitor outputs
- Compact 1/3U rack-mount chassis
- Sealed, detented, metal rotary controls
- External 16 VAC power supply
SPECIFICATIONS
| Inputs | Headphone Outputs | |||
| Connector Type | ¼” TRS, balanced | Connector Type | ¼” TRS, stereo | |
| THD+N | 0.0025%, 1 kHz, unity gain | Max Output Power | 130 mW/Ch., <0.5% THD+N, 60Ω load | |
| Max Input Level | +18 dBu, <0.5% THD+N, unity gain | Frequency Response | 20 Hz - 20 kHz, ±0.5 dB, 60Ω load | |
| Input Impedance | 10 kΩ | Headphone Impedance Working Range | 32Ω - 600Ω | |
| Frequency Response | 20 Hz - 20 kHz, ±0.5dB | Power | ||
| Monitor Outputs | External Adapter Type | +12 VDC, 1000 mA, center pin positive | ||
| Connector Type | ¼” TRS, asymmetrical, impedance-balanced | Physical | ||
| THD+N | 0.0025%, 1 kHz, unity gain | Dimension | 1/3U rack-mount (with standard rack tray, not included) | |
| Max Output Level | +18 dBu, <0.5% THD+N | Height | 1.75” (44.45 mm) | |
| Output Impedance | 51Ω | Depth | 5.5" (139.7 mm) | |
| Frequency Response | 20 Hz - 20 kHz, ±0.5dB | Width | 5.5” (139.7 mm) | |
| Weight | 5 lbs (2.27 kg) |
