RolandTR6S Drum Machine
Show all:
Drum Machines,Drums & Percussion
Description
Read moreRead less
The Roland TR-6S Drum Machine packs iconic TR sounds into a compact, portable design. With powerful beats, hands-on control, and modern features, it’s perfect for creating music anywhere.
FEATURES
- Six-track version of the TR-8S in a compact and affordable package
- Detailed circuit models of the Roland TR-808, TR-909, TR-606, TR-707, CR-78, and more
- Large preset sample library with support for custom user samples
- Editable FM sound engine for futuristic tones
- Program basslines with the newly developed TR-808 chromatic bass instrument
- Mix and match sounds for exotic hybrid drum kits
- Advanced sequencer with sub steps, flam, step loop, motion recording, probability, sub step probability, master probability, and more
- Runs on four AA batteries or USB bus power
- Also functions as a high-quality USB audio/MIDI interface
SPECIFICATIONS
| User Drum Kit | 128 |
| User Patterns | 128 |
| User Patterns | 6 instrument parts 16 steps per 1 variation 8 (A - H) variations per 1 pattern 2 Fill-in patterns per 1 pattern |
| INST tone | (Tone can be assigned to each 6 instrument parts freely.) BASS DRUM: 11 ACB tones SNARE DRUM: 8 ACB tones TOM: 19 ACB tones RIM SHOT: 3 ACB tones HAND CLAP: 5 ACB tones HI HAT: 8 ACB tones CYMBAL: 8 ACB tones PERCUSSION: 24 ACB tones FM: 72 tones PRESET SAMPLE: 300 tones or greater USER SAMPLE (imported form SD CARD for playback): Avarable format: WAV, AIFF Total time for all samples: Approximately 600 sec (at 44.1 kHz, mono) * The maximum length of a single audio file that can be imported is approximately 180 seconds (at 44.1 kHz). * Available format of Sample: WAV 96 kHz maximum/8bits, 16 bits, 24 bits, 32 bits, 32 bits float (mono, stereo) AIFF 44.1kHz, 48kHz, 96 kHz/8bits, 16 bits, 24 bits, 32 bits, 32 bits float (mono, stereo) |
| Effects | INST FX: THRU, HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, COMPRESSOR, DRIVE, COMP+DRV, CRUSHER, SATURATOR, FREQ SHIFT, RING MOD, SPREAD REVERB: AMBI, ROOM, HALL1, HALL2, PLATE, MOD, HA-DOU DELAY: DLY, PAN, TAPE ECHO, PITCH SHIFT MASTER FX: HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, TRANSIENT2, COMPRESSOR, DRIVE, OVERDRIVE, DISTORTION, FUZZ, CRUSHER, PHASER, FLANGER, SBF, NOISE, FATTENER, VINYL SIM Other: SCATTER (as one of AUTO FILL IN function), SIDE CHAIN |
| Display | 16 characters, 2 line (backlit LCD) |
| External Storage | SD Card (SDHC supported) for backup/restore function and import sample data |
| Connectors | PHONES jack: Stereo miniature phone type OUT(L/MONO, R) jacks: 1/4-inch phone type MIDI(IN, OUT) connectors USB port: USB B type (Audio, MIDI) |
| Power Supply | Ni-MH battery (AA, HR6) x 4 Alkaline battery (AA, LR6) x 4 Obtained via USB port (USB bus power) |
| Current Draw | 500 mA |
| Expected battery life under continuous use | Alkaline battery: Approx. 4.5 hours Ni-MH battery: Approx. 5.5 hours (When using batteries having a capacity of 1,900 mAh.) * This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use. |
| Accessories | Leaflet "Read Me First" Alkaline battery (AA, LR6) x 4 |
| Dimensions | 224(W) x 132(D) x 60.1(H) mm 8-13/16(W) x 5-3/16(D) x 2-3/8(H) inches |
| Weight (including batteries) | 705 g | 1 lb 9 oz |
