VoxVX50 KB Keyboard Amp

The compact and lightweight VX series is joined by a new 50W model, specialized for keyboard and featuring Nutube, the new vacuum tube. With a coaxial speaker that outputs clear sound even to the high-frequency range and a bass reflex structure that reproduces rich low-frequency sound with ample power, this amp delivers high-quality sound from a compact and lightweight unit. The three-channel design provides independent volume control for each channel, and CH3 also supports mic input. This amp can also function as a simple and easily transportable PA system. A full complement of input/output jacks is also provided, including an AUX IN jack, headphone jack, and a LINE OUT jack for connection to a PA system. This amp is also ideal for on-stage use as a monitor amp.

Features

• - High 50W of output power from a revolutionary, lightweight, and compact unit.
• - The warm vacuum tube sound of Nutube.
• - Coaxial speaker delivers clear output extending to the high-frequency range.
• - Bass reflex structure ensures ample output and rich low-frequency reproduction.
• - Three-channel design, with independent volume controls.
• - Three-band master EQ for flexibly controlling the sound.
• - CH3 input can be switched between LINE/MIC, and provides a PHASE switch.
• - A rich selection of input/output jacks includes AUX in, PHONES out, and LINE out.

SPECIFICATIONS

OUTPUT POWER

• - 50 Watts RMS
• - 4 Ohms

SPEAKER

• - 1 x 8" Vox Original (2 Way Coaxial)

INPUTS

• - Channel 1 – 1 /4″ Phone Jack (unbalanced)
• - Channel 2 – 1 /4″ Phone Jack (unbalanced)
• - Channel 3 – 1 /4″ Phone Jack (unbalanced, mic/line switchable)
• - 1 x Aux In (1/8″ stereo mini-phone jack)

OUTPUTS

• - 1 x Line Out (1/4″ phone jack, unbalanced)
• - 1 x Headphone (1/8″ stereo mini-phone jack)

CONTROLS

• - 1 x Master Volume
• - 1 x Channel Volume Per Channel (1, 2, and 3)
• - Bass, Middle, Treble

TUBE COMPLIMENT

• - Nutube 6P1

DIMENSIONS (W x D x H)

• - 354 x 208 x 313 mm l 13.94 x 8.19 x 12.32
• - 4.1kg l 9.04lbs
